起源の場所: | 中国 |
ブランド名: | SCXK |
証明: | CE/ROHS/FCC/ISO/UL |
モデル番号: | P3 |
最小注文数量: | 10 sqm |
---|---|
価格: | negotiation |
パッケージの詳細: | 木の場合か飛行場合は利用できます。 |
受渡し時間: | 7-15仕事日 |
支払条件: | T/T、ウェスタン・ユニオン、MoneyGram |
供給の能力: | 1ヶ月あたりの5000sqm |
モードの運転: | 1/16のスキャン | キャビネット サイズ: | 576x576mm |
---|---|---|---|
適用:: | 屋内 | モジュールのサイズ:: | 192*192mm |
モジュールの決断:: | 64*64ピクセル | 定常電圧:: | AC100-240V |
リフレッシュ レートを:: | 3840Hz | 名前: | p3屋内パネルのビデオ壁のデジタル表記および表示はスクリーンを導いた |
ハイライト: | SMD2121段階LEDの背景の表示,800W段階LEDの背景の表示,192*192mm導かれた段階のビデオ壁 |
SCX LED full color advertising flexible indoor P3 led billboard video wall screen display panels
Unit Module Specifications | |
Item | P3 |
Pixel Pitch | 3 mm |
Pixel Configuration | 3in1 (1R1PG1B) |
Module Size(MM) | 192*192 |
Module Resolution(Dots) | 64*64 |
Module Weight(Kg) | 0.3 |
Package LED Mode | SMD2121 |
Max Power(Watt) | 21 |
Pixel Density(Dots/SQM) | 111'111 |
Driving Method | Constant Current Driving |
Scan Method(Scan) | 1/32 |
Interface Way | HUB 75 |
Brightness(CD/SQM) | ≥ 1500 |
Safety Standard | CCC,FCC,ROHS,TUV,CE,ETL,UL,BIS..... |
Unit Cabinet Specifications | |
Cabinet Size(MM) | 576*576 |
Cabinet Composing(PCS) | 9 |
Power Supply Mode(Per Cabinet) | 5V60A |
Cabinet Resolution(Dots) | 192*192 |
Optimal Viewing Distance(M) | 3-300 |
Optimal Viewing Angle | Horizontal angle: 160 degree; Vertical angle: 140 degree |
Environment Temperature | Storage: -40 degree ~ +85 degree; Work: -20 degree ~ +60 degree |
Relative Humidity | 10% ~ 95% |
Power Supply Specifications | |
Operating Voltage | AC:100V~120V AC:220~240V |
Average Power(W/SQM) | 150-350 |
Max Power Consumption(W/SQM) | ≤ 800 |
Current | ≤ 20mA (single LED) |
Control System Specifications | |
Computer | Pentium4 or above P4 or above |
Operate System | Win7-11/2000/NT/XP |
Control Mode | Synchronization with PC |
Main Technical Parameter Specifications | |
Driving Device | Constant Current Driving |
Refresh Rate | ≥ 1900-3840Hz |
Gray/Color | RGB each 256 grade, can display 16.7color |
Lifespan | ≥ 100000hours |
Power Switch | RGX Automatic Switch |
Display Mode | 2048*10241024*7681280*960mm |
For more information please contact our sales. |
Die Casting Aluminum Cabinet Details, This Cabinet Is Light, Thin And Is Easy To Intall For
Different Events.
Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
our case
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
Eachinled has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
